    BACnet Simulator PR-19

    Your one-stop solution to simulate
    any BACnet Device within Smart Building Network

    Overview

    Building automation OEMs are constrained by a lack of comprehensive, certified tools to establish BACnet communication within their product offerings.

    BACnet application development requires a physical interface with BACnet devices to test applications in real-time. Field-testing is expensive and time consuming.  Hence, interoperability and testing often occur only in the BACnet test lab at the time of certification. As a result OEMs spend a significant amount of time and incur greater expense to correct defects identified at the testing stage.


    Solution

    Softdel’s BOSS Simulator simulates a network of virtual BACnet devices, properties and service configurations, without the need for physical devices. It provides a comprehensive ability to effectively troubleshoot BACnet functionality and interoperability, without conducting field tests. Its easy-to-use interface allows developers and systems integrators to configure, monitor and issue service commands to accessible physical or virtual devices on the BACnet network.

    Using the BACnet Simulator OEMs can test applications virtually and fix any issues noticed, before sending the device for testing.

    Key Features of BOSS Simulator –

    • Simulate devices of PR-19
    • Segmentation support
    • BBMD Support
    • Backup and restore support
    • Support for both A-side and B-side services
    • User configurable simulation of PVs
    • Support IBM MS DBCS, ANSI X3.4, ISO 8859-1 character sets
    • Virtual router
    • Device discovery (searching and sorting by device ID, IP)
    • Object browser
    • Set property value of discovered objects
    • Continuously monitor property values of discovered devices
    • Auto command configuration to generate periodic commands over the network

    BOSS Simulator Vs BOSS Explorer

    The below table gives the high-level overview of features, comparison, pricing info about our products- BOSS Simulator and BOSS Explorer

    *Note- Once you make the Payment, please click on the “Return to Merchant” link to proceed further.

    Features BOSS Simulator BOSS Explorer
    $ 1350 / year

    $ 149 / year

    Protocol revision support
    Protocol revision support PR-19 PR-19
    BACnet/Ip device virtually
    Simulate BACnet/Ip device virtually X
    Discover and browse BACnet devices
    Discover and browse BACnet devices
    Object Browser
    Object Browser
    Configurable BACnet devices
    Configurable BACnet devices X
    Automatic network traffic generator
    Automatic network traffic generator X
    Monitor Object property values
    Monitor Object property values
    Set property value of discovered objects
    Set property value of discovered objects
    Segmentation support
    Segmentation support
    BBMD support
    BBMD support X
    Support for both A-side and B-side services
    Support for both A-side and B-side services X
    User configurable simulation of PVs(Present Values)
    User configurable simulation of PVs(Present Values) X
    Supports IBM MS DBCS ,ANSI X3.4 character sets
    Supports IBM MS DBCS ,ANSI X3.4 character sets
    Virtual router
    Virtual router X
    Real time logging, monitoring & analysis of BACnet commands and response
    Real time logging, monitoring & analysis of BACnet commands and response X
    Backup and restore support
    Backup and restore support X



    Below are the Steps to Install the BOSS Simulator

    1. Open folder “BOSS Simulator Installer” >> Click on setup.exe
    2. Follow instructions to complete setup
    3. Now start BOSS Simulator from Desktop or from StartUp menu
    4. Click on register button
    5. Select MAC address from list and click on generate button to generate license request file(.bnt file) and save it on local machine.
    6. Please email the .bnt file to boss_simulator@softdel.com.
    7. Once we receive .bnt file, we will email you the license file (.lic extension) within 24 working hours | Save the license file on Desktop.
    8. Start BOSS Simulator.
    9. Click on register button.
    10. Select validation radio button if not selected, browse for the saved license file.
    11. Click on validate to apply the license.

    For any support, please email us at boss_simulator@softdel.com or Click here to submit your enquiry

    Benefits

    Efficiency

    Simulate networks, reduce travel and time spent at end-customer sites

    Predictability

    Run multiple simulations, identify and fix issues before testing and installation

    Cost Saving

    Early identification of issues at pre-testing stage saves re-test expenditure

    Flexibility

    Single PC & Multi-virtual Devices + Configurations

    CASE STUDY // BOSS (BACnet Device Simulator)

    Building Internet of Things

    Client : Leading US-based Building Management Company

    Talk to our BACnet Expert

    Our technical experts will be happy to address your needs
